CLA-1™
By delivering rapid diagnosis, the safe and reliable CLA system enables allergy sufferers to begin therapy more quickly. At the heart of this innovative technology are the patented Pette and CLA-1™ Luminometer.
Device Type
Small Footprint Allergy Diagnostic Luminometer System
Application Area
Immunology
Client
Hitachi Chemical Diagnostics
Role of BIT
Product Development, Manufacturing, After-Sales Services
History
Since 1991
Hitachi Chemical Diagnostics’ CLA® Allergy Test is a cost effective, compact and flexible system that measures a patient’s response to several allergens simultaneously with one serum sample.
The CLA technology is semi-quantitative and requires only one serum sample, making it less invasive to the patient. By delivering rapid diagnosis, the safe and reliable CLA system enables allergy sufferers to begin therapy more quickly. At the heart of this innovative technology are the patented Pette and CLA-1™ Luminometer.
| Test Type | Chemiluminescent Assay |
| Sample Types | Serum |
| Sample Volume | < 1.5 mL |
| Assay Applications | 36 Specific IgE |
| Throughput | 180 Allergens or 5 Panels/ 10 min |
| Walk Away Time | > 10 min |
| Time to First Result | < 10 min |
| Analysis Type | Sequential |
| Sample Loading Capabilities | Manual Processing 5 Panels/ run |
| Input & Output | RS232 C Printer |
| Interface | Fluorescent Display |
| Dimensions | 23 cm x 32 cm x 43 cm (H x W x D) |
| Weight | 8.5 kg |
| Power | AC 100-240 V 50/60 Hz |
