Innovance® PFA-200
The INNOVANCE® PFA-200 System* provides a simple, rapid, qualitative, and precise automated assessment of platelet function and supports clinically relevant decision-making processes affecting therapies.
Device Type
Rapid Platelet Dysfunction Detection System
Application Area
Hematology
Client
Siemens Healthineers
Role of BIT
Manufacturing, After-Sales Services
History
Since 2013
The INNOVANCE® PFA-200 System provides a simple, rapid, qualitative, and precise automated assessment of platelet function and supports clinically relevant decision-making processes affecting therapies.
The system quickly measures platelet plug formation in a small whole blood sample (800 μL) and reports a ”closure time” in 5-8 minutes.
| Test Type | High-shear force dynamic flow system |
| Sample Types | Citrated whole blood |
| Sample Volume | < 800 μl |
| Assay Applications | Hemostasis Dade PFA Measurement Cells COL/ADP Dade PFA Measurement Cells COL/EPI INNOVANCE© PFA P2Y Measurement Cells |
| Throughput | Single Test: 6 Tests/hr Double Test: 10 Tests/hr |
| Walk Away Time | n/a |
| Time to First Result | 5-8 min |
| Analysis Type | Sequential |
| Sample Loading Capabilities | Manual Pipette Dispensing |
| Input & Output | RS232 DB-9 Ethernet USB port |
| Interface | Color LCD Touchscreen |
| Dimensions | 37.4 cm x 37.3 cm x 25.6 cm (H x W x D) |
| Weight | 10 kg |
| Power | AC 110 – 220 V 50/60 Hz 300 W |
