HYBRiD-XL®
The DRG HYBRiD-XL ® allows the simultaneous measurement of immunoassays and clinical chemistry parameters, including turbidimetric tests in one sample.
Device Type
Fully Automated Continuous Access Analyzer
Application Area
Clinical Chemistry, Immunology
Client
DRG Instruments GmbH
Role of BIT
Product Development, Manufacturing, After-Sales Services
History
Since 2009
Using innovative and unique technology the DRG HYBRiD-XL ® allows, for the first time, the simultaneous measurement of immunoassays and clinical chemistry parameters, including turbidimetric tests in one sample.
The lab top analyzer is ideal for medium-sized and small laboratories, clinics, and large medical practice facilities.
Up to 40 tests of different types or 40 times of the same test, or up to 40-patient samples can be ordered by the medical practitioner over a wide range of pre-packaged tests to serve different specialties.
| Test Type | ELISA Clinical Chemistry Immunoturbidimetry |
| Sample Types | Serum, Plasma, Urine, Saliva |
| Sample Volume | > 5 µL |
| Assay Applications | Fertility, Tumor marker, Thyroid Function, Prenatal Supervision, Diabetes, Bone Metabolism, Iron Metabolism, Hypertension, Cardiac Marker, Nephrology, Salvia, Infectious Diseases, Therapeutic Drug Monitoring, Inflammation, Autoimmune Diseases, Allergy |
| Throughput | ELISA: up to 200 Tests/day (8h) ClinChem: up to 100 Tests/h (1-reagent) |
| Walk Away Time | > 1.5 h for ELISA |
| Time to First Result | 10 min for ClinChem 1.5 h for ELISA |
| Analysis Type | Random Access STAT Reload samples (exchange of 2 x 12 primary tubes or 1 x 20 secondary tubes) during a run |
| Sample Loading Capabilities | Up to 36 Samples/ Run ( 3 x 12 primary tubes) Up to 40 samples/run (2 x 20 secondary tubes) |
| Input & Output | LIS Ethernet USB Printer |
| Interface | 8.5 Inch TFT Color Touchscreen |
| Dimensions | 58.6 cm x 60.8 cm x 63.5 cm (H x W x D) |
| Weight | 60 kg |
| Power | AC 100-250V 50/60Hz 300W |
